Using AWS EBS Volumes in Kubernetes To Store Persistent Data for Kubernetes Versions > 1.23

AWS EBS!!

I had written a speedrun on how to create persistent volume claims using AWS EBS in a previous mentioned blog post here. However the steps shown there won’t work for kubernetes clusters version above 1.23 due to a feature enabled in these versions called CSI Migration. So some additional steps have to be taken to create PVC’s for these versions as shown below:

An IAM Role needs to be attached to the worker nodes with the following permissions :

{
“Version”: “2012–10–17”,
“Statement”: [
{
“Effect”: “Allow”,
“Action”: [
“ec2:AttachVolume”,
“ec2:CreateSnapshot”,
“ec2:CreateTags”,
“ec2:CreateVolume”,
“ec2:DeleteSnapshot”,
“ec2:DeleteTags”,
“ec2:DeleteVolume”,
“ec2:DescribeAvailabilityZones”,
“ec2:DescribeInstances”,
“ec2:DescribeSnapshots”,
“ec2:DescribeTags”,
“ec2:DescribeVolumes”,
“ec2:DescribeVolumesModifications”,
“ec2:DetachVolume”,
“ec2:ModifyVolume”
],
“Resource”: “*”
}
]
}

Next we need to install AWS EBS CSI Driver using helm as shown below:

helm repo add aws-ebs-csi-driver https://kubernetes-sigs.github.io/aws-ebs-csi-driverhelm repo updatehelm upgrade — install aws-ebs-csi-driver \
— namespace kube-system \
— set enableVolumeScheduling=true \
— set enableVolumeResizing=true \
— set ‘podAnnotations.iam\.amazonaws\.com/role’=ROLE_ARN \
— set ‘node.podAnnotations.iam\.amazonaws\.com/role’=ROLE_ARN \
aws-ebs-csi-driver/aws-ebs-csi-driver

Here ROLE_ARN is the kubernetes role assigned to kubernetes worker node

Next we can create a storage class using the below example where values can be accordingly changed. Pay attention as it’s slightly different from the one generally used:

kind: StorageClass
apiVersion: storage.k8s.io/v1
metadata:
name: aws-ebs-k8
labels:
deploy: aws-ebs-k8
namespace: monitoring
provisioner: ebs.csi.aws.com
volumeBindingMode: Immediate
parameters:
type: gp2 # This configures SSDs (recommended).
allowVolumeExpansion: true
reclaimPolicy: Retain
allowedTopologies:
- matchLabelExpressions:
— key: topology.ebs.csi.aws.com/zone
values:
— us-west-2b

Now we can create a persistent volume claim directly by using the storage class name which we configured above:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
labels:
deploy: pvc-k8
name: pvc-k8
spec:
accessModes:
— ReadWriteOnce
resources:
requests:
storage: 20Gi
storageClassName: aws-ebs-k8

Applying this configuration would create a persistent volume claim as well as an EBS volume , and further the claim can be used to attach to a kubernetes application.

--

--

--
